About Low elasticity resistance and high corrosion proof NON-CHROME film

As magnesium die casting product is beneficial in recycling and eco-friendly aspect as a method to supplement the demerit in aluminum die casting and plastic emission, we would like to introduce NON-CHROME film treatment process and used chemicals that developed surface treatment (existing CHROEM TYPE) to respond to it, please refer to the below and give us guidance and encouragement.

1. Characteristics

1) The film itself is high corrosion proof
2) Electricity resistance is good
3) The performance of the film for lower coating extremity is excellent.

2. Treatment process

Material: Magnesium die casting (AZ91D)

Treatment condition: Noisol fat removal medicine #MG-15(45%, 60C, 5minutes) -> washing -> Niosol wanderer #MG-108 (10%, 30C, 50seconds) ->washing -> Noisol wanderer #MG-15(45%, 90C, 7minutes) -> washing -> Noisol film maker #MG-1000(2.5%, 35C, 40seconds) -> washing -> pure washing -> dry off oven(80C, 10minutes)

(1) Coating film

Item

Performance

element adherence amount

70~120

50~85

100~160

Surface electricity
resistance value

0.02~1.0

film itself corrosion resistance
(salty water spray 24H)

no discoloration,
and no corrosion

* Mitzmibi Co., Ltd. resistance rate rollestar: MP2 terminal flow measurement

SEM picture (X500)

(2) coating performance

Coating: coating for solvent 2C x 2B (acryl resin total thickness 60μm)

estimation :

(1) 1st clinging check: 1mm checks tape exfoliation experiment (100/100)

Strength of painting film: after hardening by gluing Ø1/2 weight to painting film, then estimate the destruction strength with alcometer after cutting around.

(2) Moisture resistance check: 50'c, more than 95% RH, 1mm Cross Cut exfoliation test after 100 hours(100/100)

(3) Check of boiling water resistance: deposition into boiling water for 1 hour and then 1mm cross cut exfoliation test(100/100)

(4)Salty water spray resistance check: measure blister width of painting film of scratch part after 72 hours ((JIS Z 2371)

Item	Performance
1st clinging	Cross Cut: 100/100
Moisture proof	100/100
Boiling water resistance	100/100
Salty water spray resistance	Green Blister, hemi-facial: below 0.5mm

Item		Performance
element adherence amount		70~120
		50~85
		100~160
Surface electricity resistance value		0.02~1.0
film itself corrosion resistance (salty water spray 24H)		no discoloration, and no corrosion
